1-8
The 4010 is compatible with the equipment listed below provided all equipment
meets the applicable agency listings for the intended use.
4003 Voice Control Panel (VCP). Since the 4010 does not contain
hardwired monitor points, the alarm/trouble output from the 4003 is
connected to a Zone Adapter Module (ZAM). One of the NACs on the
4010 can be used to activate the 4003.
4009A and 4009R IDNet NAC Extender.
The 4010 is compatible with the following 4098 smoke/heat sensors and
bases:
PID Description
4098-9710 Quickconnect, TrueAlarm, Photo
Smoke Sensor
4098-9713 Quickconnect, TrueAlarm, Photo
Smoke Sensor with sounder.
4098-9714 TrueAlarm, Photo Smoke Sensor
(requires separate base)
4098-9717 TrueAlarm, Ion Smoke Sensor
(requires separate base)
4098-9733 TrueAlarm Heat Sensor (requires
separate base)
4098-9789, -9791 thru -9793 Sensor Bases
Power supplies that are power-limited and listed for fire-protective signaling
use can be used with the 4010 when wired according to power-limited
guidelines.
The 4010 is compatible with the 4120 network. In order to use the 4010 as
a node on the network, you must have
- 4100 master software must be Rev. 8.01 or higher and GCC/NPU must
be Rev. 2.03 or higher.
- 4120 network firmware must be Rev. 3.01 or greater. (Rev. 3.02.99 or
later is recommended.)
- 4010 network firmware must be Rev. 3.03.99 or later.
Optional System Modules, Continued
Other Compatible Equipment
Technical Manuals Online! - http://www.tech-man.com
