Simplex 4010 User Manual

6-4
6. Use <NEXT> or <PREVIOUS> to scroll through your choices until <Edit
IDNet Point> is displayed and then press Enter.
7. Press <NEXT> or <PREVIOUS> to scroll through your list of TrueAlarm
points until the desired point is displayed and then press Enter.
8. Press <NEXT> or <PREVIOUS> to scroll through your list of choices until
the desired option is displayed and then press Enter. Your choices are
shown in Table 6-1.
Table 6-1. TrueAlarm Configuration Choices
Function Description
Edit Device Type
(See Note 1)
Changes the Hardware Device Type of the Point
Edit Point Type
(See Notes 1 and 2)
Changes the Software Point Type of the Point
Edit Point Label
(See Note 2)
Changes the 40-Character Label of the Point
Clear Point Label
(See Note 2)
Blanks the 40-Character Label of the Point
Edit Mode
(See Note 1)
Changes the Mode of Operation for the Point
Notes:
1. For a complete list of your choices for these edit functions, refer
to “Appendix A. Device and Point Types.”
2. To complete these functions, refer to their appropriate section
in this publication.
Use the following steps to delete a TrueAlarm point from the 4010 FACP.
1. Press <MENU>.
2. Press <NEXT> or <PREVIOUS> until [PROGRAMMING] is displayed
and then press <ENTER>. A warning appears, indicating that the 4010 is
no longer in the Fire Alarm Operation mode.
3. Press <ENTER> to continue.
Continued on next page
Configuring TrueAlarm Points, Continued
Edit TrueAlarm Point
(continued)
Delete TrueAlarm Point
Please Wait . . .
Fire Alarm Operation Suspended
Technical Manuals Online! - http://www.tech-man.com

Simplex 4010 Specifications

General

Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Manufacturer	Simplex
Model	4010
Battery Backup	24 VDC
NAC Outputs	4
Max Detectors	250
Max Modules	250
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	Up to 93% RH, non-condensing
