1-13
To execute any of the functions protected at Level 2 or above, you must Login to
the 4010 FACP using a passcode. After completing a task at a certain access
level you should then Logout to return the access level to Level 1. When logged
in at Level 2 or above and you do not press any front panel keys for more than
ten minutes, the 4010 defaults to access level 1.
All passcodes consist of a four-digit number. Logging in at a Level 4 causes a
Service Mode trouble. Note that this trouble can only be cleared by restarting
the panel.
To Login, perform Steps 1 through 7 on a 4010 that is at the High-Level Status
screen (refer to Figure 1-2 for an example of this screen). When moving from
one digit to the next, an asterisk (∗) appears in the place of an entered number
for security purposes. See Table 1-2 in the previous section for the default
passcodes.
1. Obtain the appropriate passcode information for the appropriate level.
2. Press <MENU>.
3. Press and hold <óNEXT> until [Login/Logout] is displayed, and then press
<ENTER>.
4. Press and hold <óNEXT> until [Login] is displayed, and then press
<ENTER>.
5. Press <óNEXT> to scroll through the numbers on the display until the
appropriate number is displayed.
6. Press the right arrow <ö> to move the focus brackets [ ] to the next digit
in the passcode.
Repeat Steps 5 & 6 until all numbers are entered.
7. When the passcode is correct, press <ENTER> to Login.
A **Login Accepted** screen indicating your current access level is displayed
briefly upon a successful Login attempt. If you did not enter the appropriate
Login passcode, a **Login is Invalid** screen appears.
To Logout, perform Steps 1 through 4 above except for Step 4 where you need
to wait until [Logout] is displayed.
Passcodes, Access Levels, and Logging In and Out, Continued
Logging In and Out
Overview
