B-6
Table B-5. Points on the Power Supply Card
Point Label Description
2-1 AC Power This trouble point will indicate that the AC line voltage is too low for
proper system operation.
2-2 Positive Earth Ground This trouble point indicates that there is a fault condition between
+24V and Earth.
2-3 Negative Earth Ground This trouble point indicates that there is a fault condition between 0V
and Earth.
2-4 Expansion Power Supply This trouble point indicates Expansion Power Supply trouble. Only
occurs if expansion supply is configured.
2-5 Expansion Power Supply
Battery
This trouble point indicates Expansion Power Supply AUX Battery
Power trouble. Only occurs if expansion supply is configured.
2-6 Battery Low This trouble point indicates that the battery has a voltage less than
22.8V.
2-7 Battery Depleted or
Disconnected
This trouble point indicates that the battery has a voltage less than
19.5V.
2-8 Battery Low Cutout This trouble point indicates that AC Power has been lost and the
batteries have reached a depleted state, the system shuts off.
2-9 Battery Charger This utility point indicates the status of the battery charger (on/off).
The IDNet Card is required for all 4010 configurations, and is located at Card
Address 3. The IDNet Card defaults to a configuration with no hardware points
(devices). However, up to 250 devices may be programmed for the IDNet Card.
The IDNet Card also includes eight card status points.
The IDNet Card has eight card status points associated with it. Table B-6
describes the card status points for the IDNet card.
Continued on next page
Hardware Points, Continued
Power Supply Points
(continued)
IDNet Card
IDNet Card Status Points
