Simplex 4010 User Manual

5-2
All card addresses (whether hardware or logical cards) are shown in Table 5-1.
Table 5-1. 4010 Card Addresses
Card Address Reserved Cards
0 CPU Board
1 NAC/Relay circuits
2 Power Supply
3 IDNet Channel
4 Dual RS232 or Service Modem
5 - 7 Unused
8 4120 Network or DACT cards
9 - 14 N2 Slaves (24-Point I/O or LCD Annunciator)
15 - 16 Unused
17 4009 IDNet NAC Extender
18 System Digital Pseudo Points
19 User Digital Pseudo Points
20 System Analog Pseudo Points
21 User Analog Pseudo Points
22 System List Pseudo Points
23 User List Pseudo Points
Card Addresses
Card Addresses
Technical Manuals Online! - http://www.tech-man.com

Simplex 4010 Specifications

General

Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Manufacturer	Simplex
Model	4010
Battery Backup	24 VDC
NAC Outputs	4
Max Detectors	250
Max Modules	250
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	Up to 93% RH, non-condensing
