3-10
Use the following steps to apply AC and battery power to the 4010 FACP.
1. Re-connect the AC power harness removed in previous steps
2. Connect the crimped ends of the 733-945 battery harness (733-903 for
Canadian systems) to the batteries. Observe polarity (red to +, black to -)
when connecting batteries.
WARNING: Battery contains sulfuric acid which can cause severe
burns to the skin and eyes, and can destroy fabrics.
Replace any leaking or damaged battery. If contact is
made with sulfuric acid, immediately flush skin or eyes
with water for 15 minutes and seek immediate medical
attention.
Caution: Notify fire, central station, and/or building personnel before
testing the system.
Power-Up
After applying power to the system, use the following list to check the 4010 for
proper operation.
• Check that the green AC Power LED is ON.
• Check that all yellow and red LEDs are OFF.
• Use the Lamp Test procedure in “Chapter 11 - Operation” of this
publication to verify that all 4010 LEDs and LCD segments work properly.
On power-up, the 4010 performs the following:
• Displays revision of boot-loader software
• Self Test - CPU Hardware Checkout
• Linkscan - Checking for a Programmer Unit Connection
• Memory Scan - Checking for Incorrect Application
• Start up - 4010 FACP Startup
Figure 3-9. 4010 Start Up Screen
Continued on next page
System Power-Up and Checkout
Connect AC & Battery Power
Power-Up and Checkout
Start up
