Simplex 4010 User Manual

B-11
Table B-13. Points That May Be Configured on Network Card
Point Label Description
NetPt1 None This point is the Network Common Trouble Point. This point is public on the
network.
NetPt2 None This point contains the Network Type, Class, Destination, and Reference for the
second network public point.
NetPt3 None This point contains the Network Type, Class, Destination, and Reference for the
third network public point.
↓
↓
NetPt510 None This point contains the Network Type, Class, Destination, and Reference for the
510th network public point.
NetPt511 None This point contains the Network Type, Class, Destination, and Reference for the
511th network public point.
The 4010 can have up to six annunciator cards added to the system. One of
these cards is the 24I/O card. The 24I/O card can reside at addresses 9 through
14. There are 24 hardware points and two card status points associated with the
24I/O card.
The 24I/O Card has two card status points associated with it. The following
table describes the card status points for the 24I/O card.
Table B-14. Status Points on the 24I/O Card
Point Label Description
Card-CS1* Missing Card This trouble indicates that the card is not communicating with the master.
Card-CS2 Wrong Card This trouble indicates that the card returned a card type as something other
than an 24I/O card type.
*CS = Card Status
Continued on next page
Hardware Points, Continued
Network Points (continued)
24I/O Card
24I/O Card Status Points
Hardware/Pseudo Points
