B-16
Table B-20. System Pseudo Points (Continued)
Point Type Label Description
D14 RW T City Disconnect On if city circuit is disconnected.
D15 R T City Circuit Trouble On if city circuit is in trouble.
D16 - AHJ City Reset Utility Point On if city circuit reset is enabled.
D17 RW T Control Point Bypass On if control points are bypassed.
D18 RW T Elevator Bypass On if elevator recall points are bypassed.
D19 RW T Doorholder Bypass On if doorholder points are bypassed.
D20 RW T Verification Tally Limit Exceeded On when any verified points tally limit
exceeds10. Off when all points tally limit
is below 10.
D21 R T Walk Test Active in System On when Walk Test is active.
D22 R U Earth Fault Latch On when Earth Fault Latch diagnostic is
active.
D23 R T TrueTest Active in System On when TrueTest is active.
D24 R T Programming Mode - System
Disabled
On when Programming or Quick-CFIG is
entered. Panel is no longer operational.
D25 RW U System Reset Activated On when System Reset Starts.
D26 RW U Alarm Silence Activated On when Alarm Silence Starts.
D27-D30 - Reserved System Pseudo Point Unused.
D31 R U Network Running in Style 4 On if network is running in Style 4.
D32- D35 Reserved System Pseudo Point Unused.
D36 R U No CRT Connected On if no set-host session is active on
network card.
D37- D44 - Reserved System Pseudo Point Unused.
D45 RW T Duplicate IDNet Device Detection
Active
When on (either through front panel or
SMPL) it enables the duplicate device
detection diagnostic on the IDNet card.
D46 - Weak Answer When on (either through front panel or
SMPL) it detects devices beyond
specifications by reducing sensitivity of
receiver.
D47 R T Event Queue Overflow On when the RS232/LCD annunciator
event queue is overflowed and events
have been missed. Panel restart clears
the trouble.
Continued on next page
Pseudo Points, Continued
4010 System Digital Pseudos
(continued)
