Table 6-3. Relay and NAC Point Configuration Choices

Function Description

Edit Device Type

(See Note 2)

Changes the Hardware Device Type of the Point

Edit Point Type

(See Notes 2 and 3)

Changes the Software Point Type of the Point

Edit Point Label

(See Note 3)

Changes the 40-Character Label of the Point

Clear Point Label

(See Note 3)

Blanks the 40-Character Label of the Point

Edit Mode

(See Notes 1 and 2)

Changes the Mode of Operation for the Point

Notes:

1. This function not allowed for NAC and Relay points.

2. For a complete list of your choices for these edit functions, refer

to “Appendix A. Device and Point Types.”

3. To complete these functions, refer to their appropriate section

in this publication.

Configuring Relay and NAC Points, Continued

Procedure (continued)
