Operation 4
Traction
Maximum climbing capability
Maximum climbing capability [%]
Model
Type
With load Without load
RX20-14C 6219 30.3 27.9
RX20-16C 6220 27.6 26.0
RX20-16 6221 28.0 27.4
RX20-16L 6222 27.4 28.7
RX20-18 6223 25.1 26.0
RX20-18L 6224 25.3 28.3
RX20-20L 6225 23.0 26.9
RX20-16P 6226 27.8 27.8
RX20-16PL 6227 27.6 28.9
RX20-18P 6228 24.8 26.0
RX20-18PL 6229 25.4 28.6
RX20-20P 6230 22.9 25.1
RX20-20PL 6231 23.1 27.2
Legend for model
C
Compact
L
Long
P
Swingaxleversion
The ascending and descending gradients
must not exceed the gradients listed above
and must have a rough surface.
The top and bottom of the gradient must
feature smooth and gradual transitions to
prevent the load from falling to the ground or
the truck being damaged.
Warning in the event that components
protrude beyond the truck contour
Trucks are often required to drive through very
narrow or very low spaces such as aisles or
containers. The dimensions of the trucks are
designed for this purpose. However, movable
components may protrude beyond the truck
563
68011531 EN - 06/2019 - 02 137
