6 Technical data
VDI datasheet: RX20-14C with steer
ing turntable
Model RX20-14C
Type number
6219
Tyre size, rear
125/75-8
Number of front wheels
(x = driven)
2x
Number of rear wheels
(x = driven)
2
Track width, front
b
10
(mm)
932
Track width, rear
b
11
(mm)
168
.
Basic dimensions
Model RX20-14C
Type number
6219
Forward tilt of lift mast/fork carriage α (degrees)
5
Backwards tilt of lift mast/fork
carriage
β (degrees)
6
Height with li
ft mast retracted
h
1
(mm)
2160
Free lift
h
2
(mm)
150
Lift
h
3
(mm)
3180
Height with li
ft mast extended
h
4
(mm)
3742
Height abo
ve overhead guard (cab)
h
6
(mm) 2035 (1949
)
Seat heig
ht/standing height
h
7
(mm)
965
Coupling
height
h
10
(mm)
473
Overall
length
l
1
(mm)
2661
Length i
ncluding fork back
l
2
(mm)
1861
Overall width
b
1
(mm)
1099
Fork arm thickness
s(mm)
40
Fork arm width
e (mm)
80
Fork arm length
l(mm
)
800
Fork carriage
Standard;
class; form
ISO2328IIA
Fork carriage width
b
3
(m
m)
980
Ground clearance with load below
lift mast
m
1
(mm)
≥90
Ground clearance at the middle of
the wheelbase
m
2
(mm)
114
402
