Technical data 6
VDI datasheet: RX20-14C with steer
ing turntable
Model RX20-14C
Type number
6219
Aisle width for pallet
1000 x 1200 crosswise
A
st
(mm)
3186
Aisle width for pallet
800 x 1200 longitudinal
A
st
(mm)
3311
Turning radius
W
a
(mm)
1487
Smallest pivot point distance b
13
(mm)
—
.
Performance data
Model
RX20-14C
Type number
6219
Driving speed with load (Blue-
Q/STILL Classic/sprint mode)
km/h 16/16/20
Driving speed without load (Blue-
Q/STILL Classic/sprint mode)
km/h 16/16/20
Lifting speed with load (Blue-
Q/STILL Classic/sprint mode)
m/s 0.54
Lifting speed without load (Blue-
Q/STILL Classic/sprint mode)
m/s
0.75
Lowering
speed with load
m/s
0.5
Lowerin
g speed without load
m/s
0.5
Pulling force with load
N 5100
Pulling force without load
N 5100
Max. pulling force with load
N 12300
Max. pulling force without load
N 7700
Climbing capability with load
%
20.4
Climbing capability without load
%24
Max. climbing capability with load
% 30.3
Max. climbing capability without
load
% 27.9
Acceleration time with load (Blue-
Q/STILL Classic/sprint mode)
s
5.7/5.4/5.1
Acceleration time without load
(Blue-Q/STILL Classic/sprint mode)
s
5.4/5.1/4.8
Service brake
Electr./mech.
.
563
68011531 EN - 06/2019 - 02 403
