Still RX20-20L - Page 420

6 Technical data
VDI datasheet: RX20-16 with steeri
ng turntable
Model RX20-16C RX20-16 RX20-16L
Type number
6220 6221 6222
Tyre size, rear
125/75-8 125/75-8 125/75-8
Number of front wheels
(x = driven)
2x 2x 2x
Number of rear wheels
(x = driven)
222
Track width, front
b
10
(mm)
932 932 932
Track width, rear
b
11
(mm)
168 168 168
.
Basic dimensions
Model RX20-16C RX20-16 RX20-16L
Type number
6220 6221 6222
Forward tilt of lift mast/fork carriage α (degrees)
555
Backwardstiltofliftmast/fork
carriage
β (degrees)
666
Height with li
ft mast retracted
h
1
(mm)
2160 2160 2160
Free lift
h
2
(mm)
150 150 150
Lift
h
3
(mm)
3180 3180 3180
Height with li
ft mast extended
h
4
(mm)
3742 3742 3742
Height abo
ve overhead guard (cab)
h
6
(mm) 2035 (1949
)
2035 (1949
)
2035 (1949
)
Seat heig
ht/standing height
h
7
(mm)
965 965 965
Coupling
height
h
10
(mm)
473 473 473
Overall length l
1
(mm)
2661 2744 2852
Length including fork back l
2
(mm)
1861 1944 2052
Overal
l width
b
1
(mm)
1099 1099 1099
Fork arm thickness
s(mm)
40 40 40
Fork arm width
e (mm)
80 80 80
Fork arm length
l (mm)
800 800 800
Fork carriage
Standard;
class; form
ISO 2328 II A ISO 2328 II A ISO 2328 II A
Fork carriage width
b
3
(
mm)
980 980 980
Ground clearance with load below lift
mast
m
1
(mm)
≥90 ≥90 ≥90
Ground clearance at the middle of
the wheelbase
m
2
(mm)
114 114 114
406
56368011531 EN - 06/2019 - 02
