Technical data 6
VDI datasheet: RX20-16 with steeri
ng turntable
Model RX20-16C RX20-16 RX20-16L
Type number
6220 6221 6222
Aisle width for pallet
1000 x 1200 crosswise
A
st
(mm)
3186 3269 3377
Aisle width for pallet
800 x 1200 longitudinal
A
st
(mm)
3311 3394 3502
Turning radius
W
a
(mm)
1487 1570 1678
Smallest pivot point distance b
13
(mm)
———
.
Performance data
Model
RX20-16C RX20-16 RX20-16L
Type number
6220 6221 6222
Driving speed with load (Blue-
Q/STILL Classic/sprint mode)
km/h 16/16/20 16/16/20 16/16/20
Driving speed without load (Blue-
Q/STILL Classic/sprint mode)
km/h 16/16/20 16/16/20 16/16/20
Lifting speed with load (Blue-
Q/STILL Classic/sprint mode)
m/s 0.53 0.53 0.53
Lifting speed without load (Blue-
Q/STILL Classic/sprint mode)
m/s
0.75 0.75 0.75
Lowering
speed with load
m/s
0.51 0.51 0.51
Lowerin
g speed without load
m/s
0.5 0.5 0.5
Pulling force with load
N 5100 5100 5100
Pulling force without load
N 5200 5200 5200
Max. pulling force with load
N 12300
12,300 12,300
Max. pulling force without load
N 7700 7900 8500
Climbing capability with load
%
18.6 18.6 18.6
Climbing capability without load
%242424
Max. climbing capability with load
% 27.6 28 27.4
Max. climbing capability without
load
% 26 27.4 28.7
Acceleration time with load (Blue-
Q/STILL Classic/sprint mode)
s
5.7/5.4/5.1 5.7/5.4/5.1 5.7/5.4/5.1
Acceleration time without load
(Blue-Q/STILL Classic/sprint mode)
s
5.4/5.1/4.8 5.4/5.1/4.8 5.4/5.1/4.8
Service brake
Electr. /
mech.
Electr. /
mech.
Electr. /
mech.
.
563
