Technical data 6
Battery specifications
Battery specifications according to DIN 43531; cells in accordance with DINEN60254-2,48V
circuit A or 48 V circuit B
Battery compartment
dimensions [mm]
Battery
designation
Capacity
[Ah]
Circuit
Weight/
ballast
weight [kg]
Length
Width
Height
Tray
4PzV 400 400
4PzV 440 440
4PzS 460
460
4PzS 500
500
A
708/
155
830 522 627 364
5PzV 500 500
5PzV 550 550
5PzS 575
575
5PzS 625
625
A 856 830 630 627 365
6PzV 600 600
6PzV 660 660
6PzS 690
690
6PzS 750
750
A 1064 830 738 627 366
5TCSM 660
660
5PzV 500 500
5PzV 550 550
5PzS 575
575
5PzS 625
650
B
1
856 1030 529 627 315
NOTE
When converting to TENSOR
®
batteries, the
maximum speed of the truck must be limited
to 17 km/h for technical reasons. Contact
the authorised service centre regarding this
matter.
Battery requirements for use in poten-
tially explosive areas
Batteries for use in potentially explosive areas
are designed and specifically tested in respect
of the zones and temperature ranges in which
they are to be used. The permitted area of use
1
In some trucks, an adapter plate is required to support the battery and circuit B.
563
68011531 EN - 06/2019 - 02 427
