13.18 X-Y AXIS ASSEMBLY PARTS LIST
ID Description Quantity
1 "Y-Axis Assembly Exploded View" (page274) 1
2 "Y-Axis Saddle Exploded View" (page277) 1
3 "X-Axis Assembly Exploded View" (page271) 1
