13.20 Z-AXIS ASSEMBLY PARTS LIST
ID Description Quantity
1 1100 Column (PN30379) 1
2 1100 Z-Axis Saddle (PN30386) 1
3 Z-Axis Gib (PN30384) 1
4 Z-Axis Gib Screw (PN30385) 2
5 Z-Axis Ball Nut Carrier (PN30387) 1
6 Z-Axis Limit Switch Flag (PN37749) 1
7 Z-Axis Motor Mount (PN30367) 1
8 1100 Z-Axis Ball Screw (PN37739) 1
9 1100 Z-Axis Ball Nut (PN37740) 1
10 Z-axis Ball Screw Upper Bumper, 1100 (PN30375) 1
11 Bearing, Angular Contact, 7202B (P6), 15 mm × 35 mm × 11 mm (PN 30373) 2
12 Bearing Spacer (PN30374) 1
13 Bearing Nut Sleeve (PN30371) 1
14 Z-Axis Bearing Retainer (PN30372) 1
15 Z-Axis Ball Screw Lower Bumper, 1100 (PN 30388) 1
16 Ball Screw Coupler (PN 30362) 1
17 Lower Bumper Washer (PN30390) 1
18 Bearing Nut, M14 × 1.5, Tab Lock (PN30363) 2
19 Bearing Nut Lock Washer, M14 (PN30364) 1
20 Motor, DCM + Brake, NEMA 34, 5.5 Nm (PN38402) 1
21 Z-Axis Drag Chain Box (PN38449) 1
22 Column Cover Plate (PN30376) 1
23 Z-axis Way Cover (PN 30378) 1
24 Z-Axis Way Cover Bracket (PN31204) 1
25 Hole Plug, Threaded PG9 (PN38458) 3
26 Hole Plug, Threaded PG7 (PN38459) 1
27 Washer, Flat, M12 (PN 32473) 6
28 Washer, Split Lock, M12 (PN 30321) 6
29 Screw, Socket Head Cap, M12 × 1.75 - 60 (PN30380) 6
30 Taper Pin, 10 mm - 55 mm (PN 30381) 2
