13: DIAGRAMS AND PARTS LISTS
©Tormach® 2023
Specifications subject to change without notice.
Page 283 Tormach 1100M® Operator's Manual (Version 1223A)
For the most recent version, see tormach.com/support
ID Description Quantity
31 Screw, Button Head Cap, M5 × 0.8 - 12, Stainless Steel (PN37716) 11
32 Taper Pin, 6 - 30 (PN30368) 2
33 Washer, Split Lock, M10 (PN 31684) 4
34 Washer, Flat, M10 (PN 30919) 4
35 Screw, Socket Head Cap, M10 × 1.5 - 40 (PN30366) 4
36 Washer, Split Lock, M5 (PN 31572) 4
37 Washer, Flat, M5 (PN39305) 4
38 Screw, Socket Head Cap, M5 × 0.8 - 25 (PN30530) 6
39 Screw, Button Head Cap (Flanged) M3 × 0.5 - 6 (PN 38880) 4
40 Eye Bolt, M16 × 2 - 28 (PN30370) 1
41 Screw, Flat Point Set, M16 × 2 - 12 (PN30369) 1
42 Screw, Socket Head Cap, M5 × 0.8 - 10 (PN31641) 1
43 M6 Lock Washer (PN31379) 5
44 Screw, Socket Head Cap, M6 × 1 - 30 (PN30353) 4
45 Nut, Hex, M5 × 0.8 (PN 31201) 2
46 Taper Pin, 6 - 35 (PN31205) 2
47 Screw, Socket Head Cap, M4 × 0.7 - 16 (PN37751) 4
48 Screw, Socket Head Cap, M5 × 0.8 - 20 (PN 30357) 9
49 Flex Conduit Fitting, 13 mm ID × 16 mm OD (PN30628) 3
50 Z-Axis Ball Screw Assembly, 1100 (PN30382) 1
