Tormach 1100M - Limit;Door Switches (Sheet 6)

15: ELECTRICAL SCHEMATICS
©Tormach® 2023
Specifications subject to change without notice.
Page 299 Tormach 1100M® Operator's Manual (Version 1223A)
For the most recent version, see tormach.com/support
15.6 LIMIT/DOOR SWITCHES (SHEET 6)
C
NC
C
NC
C
NC
LOCK SOLENOID LATCH SWITCH
12
E2
22
11
E1
21
PN 37352
LOCK SWITCH ENCLOSURE DOOR SWITCH
DS2
LS1 LS2 LS3
X-LIMIT SWITCH Y-LIMIT SWITCH Z-LIMIT SWITCH
409 410
411
414 413 412 437
ECM1 J2.1 (SHEET 5) ECM1 J2.2 (SHEET 5) ECM1 J2.3 (SHEET 5)
SOCKET PN 37357 PLUG PN 37929
PN 31860 PN 31860 PN 30461
ENCLOSURE DOOR SWITCH CONNECTOR
XS8
PN 37514
D2
400
414
ECM1 J2.6 (SHEET 5)
414 414 400437
412 413
ECM1 J2.5 (SHEET 5) ECM1 J2.4 (SHEET 5) ECM1 J10.4 (SHEET 5) 24 VDC- (SHEET 2)
412 400 437 414 413
4
1
5
2
3
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
DATE
DRAWN BY
TITLE:
SIZE
B
DWG. NO.
REV
H
1100M/MX ELECTRICAL SCHEMATIC
LIMIT / DOOR SWITCHES
SHEET 6 OF 12
37158
DO NOT SCALE DRAWING
THIS DRAWING CONTAINS PROPRIETARY AND CONFIDENTIAL INFORMATION BELONGING TO TORMACH INC. THIS DRAWING MAY NOT BE REPRODUCED OR COPIED IN WHOLE OR IN PART NOR CAN THE INFORMATION CONTAINED BE USED FOR ANY PURPOSE WITHOUT THE EXPRESS WRITTEN PERMISSION OF TORMACH INC
RRH
2018-09
1071 UNIEK DR WAUNAKEE, WI 53597 (608) 849-8381
