4: INSTALLATION
2. While looking at the Minutes display, do one of the
following:
l To increase the interval time, push the UpArrow. We
recommend that you set it to 480 minutes (eight
hours).
l To decrease the interval time, push the DownArrow.
NOTICE! Pressure Hazard:To avoid potential
equipment damage, don't set the interval time
to less than five minutes.
Specify the Actuation Time
The actuation time is the amount of time, in seconds, that the
oiler distributes oil during an oil application.
1. On the oiler's control panel, push and hold either of the
Seconds Adjustment buttons. It doesn't matter which
button you push.
The oiler beeps.
2. While looking at the Seconds display, do one of the
following:
l To increase the interval time, push the UpArrow. We
recommend that you set it to 12 seconds.
l To decrease the interval time, push the DownArrow.
NOTICE! Pressure Hazard:To avoid potential
equipment damage, don't set the actuation time
to more than three minutes.
4.8.2 Install the Power Drawbar
Complete the following steps in the order listed:
Required Tools 57
Air Requirements 57
Installation 57
Adjust the Power Drawbar 64
Required Tools
This procedure requires the following tools. Collect them
before you begin.
l Adjustable wrench (two)
l Clean cloth
l Electric drill
l Hardware to install the FRLFilter-Regulator-Lubricator
l Metric hex wrench set
l Paint pen
l Tooling to drill holes for the FRLFilter-Regulator-
Lubricator
Air Requirements
You must verify that the site conforms to the following air
supply requirements.
The Power Drawbar uses compressed air to release tools held
in the spindle.
l
Air Pressure Between 90 psi and 120 psi (620 kPa to
825 kPa).
If the air supply is more than 120 psi (825 kPa), you must
use a regulator.
l
Air Volume For successive back-to-back tool changes,
at least 2 cfm at 90 psi is required.
Exact air volume depends on the frequency of tool
changes.
l
Dry Air We recommend using a compressed air dryer,
desiccator, or filter between the air compressor and the
machine.
l
Lubricated Air You must lubricate the air with air tool
oil.
Use the FRLFilter-Regulator-Lubricator (PN 32457)
(included with the power drawbar kit) for this purpose.
Installation
Note: We're continuously improving our products, so
your machine may vary from the photos in our
documents and videos. For example, on newer
machines, the pneumatic lines are mounted on the
front of the Power Drawbar to prevent them from
getting entangled or pinched in the spindle door.
While the images may vary, the concepts still apply.
Complete the following steps in the order listed:
Prepare the Machine 58
Disassemble the Original Drawbar 58
Assemble the Power Drawbar 59
Install the FRL 61
Set Up the FRL 62
Make Air Connections 62
©Tormach® 2023
Specifications subject to change without notice.
Page 57 Tormach 1100M® Operator's Manual (Version 1223A)
For the most recent version, see tormach.com/support
