13.22 ENCLOSURE PARTS LIST
ID Description Quantity
1 Enclosure Panel, 1100, Lower Front (PN 37630) 1
2 Enclosure Panel, 1100M, Left Front (PN 37635) 1
3 Enclosure Panel, 1100M, Right Front (PN 37634) 1
4 Enclosure Panel, 1100, Upper Front (PN 37633) 1
5 Enclosure Panel, 1100M, Left Side (PN 37632) 1
6 Enclosure Panel, 1100M, Right Side (PN 37631) 1
7 Enclosure Panel, 1100, Left Top (PN 37636) 1
8 Enclosure Panel, 1100, Right Top (PN 37637) 1
9 Enclosure Panel, 1100, Left Rear (PN 37638) 1
10 Enclosure Panel, 1100, ATC (PN 37645) 1
11 Chip Tray Rail, 1100 (PN 37657) 1
12 Enclosure Panel, 1100, Right Rear (PN 37639) 1
13 Enclosure Panel, 1100, Splash Shield (PN 38691) 1
14 Enclosure Panel, 1100, Splice Plate (PN 38695) 1
15 Enclosure Panel, 1100, Column Splice (PN 37663) 1
16 Enclosure Door, 1100, Right (PN 37640) 1
17 Window, 1100, Right Door (PN 37650) 1
18 Enclosure Door, 1100, Left (PN 37641) 1
19 Window, 1100, Left Door (PN 37649) 1
20 Window, 1100, Side (PN 37648) 2
21 Enclosure Window Retainer, 1100, Vertical (PN 37646) 8
22 Enclosure Window Retainer, 1100, Horizontal (PN 37647) 8
23 LED Floodlight, 50 W (PN 37341) 2
24 Flood Light Retainer (PN 38222) 4
25 Linear Rail Mount (PN 37622) 8
26 Left Door Rail, 1100 (PN 37642) 2
27 Right Door Rail, 1100 (PN 37643) 2
28 Linear Bearing (PN 37610) 8
29 Door Bumper (PN 38357) 8
30 Handle, 400 mm (PN 37611) 2
31 Door Seal (PN 37644) 2
