13: DIAGRAMS AND PARTS LISTS
©Tormach® 2023
Specifications subject to change without notice.
Page 286 Tormach 1100M® Operator's Manual (Version 1223A)
For the most recent version, see tormach.com/support
ID Description Quantity
32 Enclosure Ball Latch, Female (PN 38482) 1
33 Enclosure Ball Latch, Male (PN 38483) 1
34 Washer, Flat, M5, Stainless Steel (PN 37939) 2
35 Nut Bar (PN 37585) 1
36 Switch Key Bracket (PN 37586) 1
37 Locking Door Switch Installation/Cover Plate (PN 38272) 1
38 Door Lock Switch Kit (PN38283) 1
39 Cable Tie Anchor, Screw Mount, M5 (PN 31460) 3
40 Round Plug, 32 mm (PN 37598) 3
41 Sealing Strip, Rubber (PN 38356) 21
42 Screw, Button Head Cap (Flanged), M6 × 1 - 12, Stainless Steel (PN 38206) 76
43 Screw, Button Head Cap (Flanged), M5 × 0.8 - 10, Stainless Steel (PN 38205) 151
44 Screw, Socket Head Cap, M5 × 0.8 - 20 (PN 30357) 8
45 Screw, Socket Head Cap, M8 × 1.25 - 22 (PN 37190) 4
46 Washer, Flat, M8 (PN 30531) 4
47 Decal, Enclosure, 1100M, Front Left Panel (PN 38746) 1
