2.2 MACHINE SPECIFICATIONS
Travels
X-Axis 18"(457 mm)
Y-Axis 11" (279 mm)
Z-Axis 16.25" (413 mm)
Spindle-to-Table MaximumClearance 18"(457 mm)
Spindle Centerline to Machine Column 11"(279 mm)
Spindle
Spindle Power 2 hp (1.5 kW)
Spindle Maximum Speed 7500 rpm
Transmission Poly-VBelt
Spindle Taper R8
Thread Machining Tension/Compression, Auto-Reversing, Thread Mill
Maximum Feed Rate
X- and Y-Axis 110 IPM(2.7 m/min)
Z-Axis 90 IPM(2.2 m/min)
Axis Motor Stepper Driven
Power
Primary Power Required Single-Phase 230 Vac, 50/60 Hz
Recommended Circuit Amperage Dedicated 20 A breaker
Table
Table Size 34" × 9.5" (864 mm × 241 mm)
T-Slot Size 5/8" (15.9 mm) (three slots)
Maximum Weight on Table 500 lb (227 kg)
Overall Dimensions
Machine Size 69" × 56"(1.8 m × 1.4 m)
Overall System Height 96"(2.4 m)
Typical System Weight 1600 lb (726 kg)
