4: INSTALLATION
4.2 BEFORE YOU BEGIN
1. Read the packing list to see if there are any items that
have not yet been delivered. We recommend waiting
until you've received all shipments to begin installing the
machine. Depending on the product and options ordered,
the system may arrive in one or more shipments of:
l Accessories(if applicable)
l Machine
Note: The machine system and large
accessories are sent by freight carrier. Smaller
accessories may be sent by parcel service.
2. Inspect the item(s):
l Photograph any damage that may have occurred
during shipping.
l Note any damage on the delivery receipt before
signing for the shipment.
l Verify the received goods against the packing list.
If there is any damage or shortages, you must contact
Tormach within 30 days of receipt. Create a support
ticket with Tormach Technical Support at
tormach.com/how-to-submit-a-support-ticket for
guidance on how to proceed.
4.3 INSTALLATION TOOLS AND ITEMS
Before uncrating and installing your machine, collect the
following tools and items.
l 4 mm hex wrench (included in tool bag)
l 1500-lb capacity engine hoist
l Assistant to help you
l Combination wrench set
l Consumables, like:
o
Anti-seize
o
Air tool oil
o
Machine way oil
l Digital multimeter
l Hammer
l Level (2 ft)
l Lifting Bar Kit (PN31446)
l Pallet jack
l Phillips screwdriver (included in tool bag)
l Pry bar
l Reciprocating saw (or similar) to break down the pallet
l Safety eyewear that meets ANSI Z87+
l Shears or knife
l Socket set
l Step ladder
l Snips
l Work gloves
4.4 MOVE THE PALLET
Tools and Items Required
l Pallet jack
Shipments arrive in crates loaded on pallets, which the freight
carrier unloads onto the curb or loading dock.
WARNING! Transportation and Lift Hazard: Before
moving the machine, you must confirm that all
persons are clear of the area below the machine.
Qualified professionals must transport, lift, and move
the machine. Moving parts can entangle, pinch, or cut
you, causing death or serious injury.
Verify that the ground surface is smooth and clean of
debris, and then use a pallet jack to move the pallet(s) to
the desired installation location.
Note: If the ground is not smooth, you may
need to use a forklift (or similar lifting
equipment rated for uneven surfaces) to move
the pallet(s).
If a pallet is too wide to fit through a doorway, see
Moving Dimensions (D40147).
4.5 ASSEMBLE THE MACHINE STAND
Tools and Items Required
l Work gloves
l Safety eyewear that meets ANSI Z87+
l Hammer
l Pry bar
l Snips
©Tormach® 2023
Specifications subject to change without notice.
Page 39 Tormach 1100M® Operator's Manual (Version 1223A)
For the most recent version, see tormach.com/support
