CHAPTER 4 TRANSMISSION SEQUENCE

B-EP Series

4-41

(4) When interrupting communication while the Graphic Data Store Command is running, and

then retransmitting data from the beginning,

1st transmission:

[1B][53][47][3B][31][2C][30][30][34][30][2C][30][30][34][30]

[2C][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF]

[FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF]



2nd transmission:

[1B][53][47][3B][31][2C][30][30][34][30][2C][30][30][34][30]

[2C][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF]

[FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF]

[FF][FF][FF][FF][FF][FF][0A][00][0D][0A]

[1B]XO;01,1[0A][00]

[1B]D0630,0480,0600[0A][00]

[1B]PC00;0030,0050,2,2,A,00,B,00,1,0[0A][00]

[1B]PC00;0030,0350,2,2,A,00,B,00,1,0[0A][00]

[1B]N;1,0150,0100[0A][00]

[1B]N;2,0150,0400[0A][00]

[1B]XP[0A][00]

[1B]X[01][21][01]Graphic Data No. 1[0A]

Graphic Data No. 2[0A][00]

Storage result: Data is properly stored, however, when it is read, a command error occurs.

Interrupts communication while

the command is running.

Transmits data from the

beginning.



1st label data

(underway)

1st label data

(retransmission

)


