CHAPTER 4 TRANSMISSION SEQUENCE

B-EP Series

4-42

(5) When interrupting communication with the Graphic Store Command separator, and

retransmitting data from the beginning,

1st transmission:

[1B][53][47][3B][31][2C][30][30][34][30][2C][30][30][34][30]

[2C][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF]

[FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF]

[FF][FF][FF][FF][FF][FF][0A][00][0D][0A]



2nd transmission:

[1B][53][47][3B][31][2C][30][30][34][30][2C][30][30][34][30]

[2C][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF]

[FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF]

[FF][FF][FF][FF][FF][FF][0A][00][0D][0A]

[1B]XO;01,1[0A][00]

[1B]D0630,0480,0600[0A][00]

[1B]PC00;0030,0050,2,2,A,00,B,00,1,0[0A][00]

[1B]PC00;0030,0350,2,2,A,00,B,00,1,0[0A][00]

[1B]N;1,0150,0100[0A][00]

[1B]N;2,0150,0400[0A][00]

[1B]XP[0A][00]

[1B]X[01][21][01]Graphic Data No. 1[0A]

Graphic Data No. 2[0A][00]

Storage result: Data is properly stored.

However, if the data retransmitted is different from the one first transmitted, the

printed output may be incomplete.

Interrupts communication with the

command separator.

Transmits data from the

beginning.



1st label data

(underway)

1st label data

(retransmission

)


