CHAPTER 5 TPCL-LE MODE (INTERFACE COMMANDS)
B-EP Series
5-96
(4) Bar width, space width, and character-to-character space
Designate the bar, space, and character-to-character space widths according to the type
of barcode. Note that the designated proper value differs according to the rotational
angle of barcode, type, number of digits, print speed, paper used, etc. Examples of such
designations are listed below.
The width of 2 to 4 modules is automatically calculated by designating a 1-module width.
[Example of setting]
203-dpi print head (1 dot = 1/8 mm)
1 module 2 module 3 module 4 module
Bar Space Bar Space Bar Space Bar Space
2 4 6 8
3 6 9 12
(5) Rotational angle of barcode
0° 90° 180° 270°
Point of origin
