CHAPTER 10 SYSTEM MODE (INTERFACE COMMANDS)
B-EP Series
10-9
[Strip position fine adjustment]
When the label-to-label gap is 3 mm,
When the label-to-label gap is 7 mm,
y In strip issue mode, printing stops at the position where the
distance between the leading edge of the strip plate and the
trailing edge of the label is 2.35 mm, regardless of gap
length. Note that this applies unless the fine adjustment
value for print position is set.
y When the print stop position is not appropriate, the stop
position must be changed using strip position fine
adjustment.
2.35 mm
3 mm to 7
mm
± 0.0 mm
- 2.0 mm
+ 3.0 mm
± 0.0 mm
- 2.0 mm
+ 3.0 mm
To Next Page
