SetupMenus A
To configure this
radio ...
Enter this number into the
Machine Radio Configuration
dialog ...
Enter the same number into the ...
SNR2400
SNR24xx
A channel between:
l
31-60 for the SPSx30
Internal UTS radio (via the UTS face
plate).
SiteNet450,
SNR410 or 12 volt
A frequency between 0-255.
The system configures the same frequency in the machine radio and also
programmes the radio as a mobile radio.
Note – If your site uses both GNSS and UTS positioning systems with 900MHz
radios, then the GNSS radios and each UTS radio must use different networks.
Note – If you have a dual band SNRxxx radio, assign a network ID to both radio
modules so that you can switch between radio bands if necessary.
A.9 Cellular modem configuration
To configure an on-machine cellular modem complete the procedures in the table
below.
Procedure To learn how see ...
Configure the system to use the cellular modem
for wireless data transfer
A.9.2 Configuring third-party cellular
modems
A.9.1 Configuring an SNM940 cellular modem
To configure the system to use an SNM940 to receive network RTK corrections
and/or for 2-way data communications, for example connecting to the Connected
Community web site:
1. Start the control box in Manager mode.
2. From the Setup Menu - Installation menu, select Machine Settings.
3. Press Edit Machine.
4.
Press 7 until you reach the Machine Settings–Positioning Radio Type
dialog:
GCS900 Grade Control System for Excavators Installation Manual 147
