B.1 Introduction
Use the information in the following sections to check that you have the correct
sensors for the system you are installing.
B.2 Device settings
Use this information if you move or swap a device:
For this device... This data ... Is stored in the ... Notes
AS450/ AS460/ LC450
sensors
Angle calibration Machine file Reconfigure the sensor if you move or
swap it. There is no need to recalibrate if
AS4x0 is swaped.
LB400 Lightbar Position
Invert
Scale or tolerance
Lightbar
Machine file
Display file
After removal, return each lightbar to the
same position. Otherwise, you must set
the lightbar connections again.
CB4x0 control box Settings Machine and display files
MS9xx GNSS
receivers
The .cfg site
configuration file
Control box design folder
or in the root directory
When you load a design, the control box
sends the .cfg file to the GNSS receiver.
Machine radio Network and
frequency settings
Machine file The control box automatically sets the
network number in the machine radio.
So, if you swap radios, the control box
will set the network number to that of the
previous radio.
B.3 System assemblies
The following table describes the various system components.
Assembly Components
Main harness System harnesses
Cab harness
Switched./ unswitched power cable
Control box Control box mounting bracket
CB4x0 control box
Boom, stick, bucket sensor Angle sensor brackets
AS45x angle sensors
158 GCS900 GradeControl System for Excavators Installation Manual
