Preparingfor anInstallation 3
you know who is providing the site (GNSS) calibration
you have a list of known site survey control points and their coordinates
Allow a full day for two experienced people to do the installation or more time for
inexperienced installers. The actual time taken will depend on the site, when you
can get access to the machine, and how long you have to wait for other
tradespeople.
3.3 Tools
Make sure that you have the following tools available:
This tool ... For...
A Multimeter Checking:
l
power
l
impedance across the CAN bus
Crimper and electrical terminals Connecting the system to machine power
Deustch crimper (P/N5401-1568), Deustch pins
and sockets
Pinning wires for the Deustch connecters
Diagonal cutters
Wire strippers and pliers
A piece of pipe or wire Feeding cables through the machine
Cable ties and wrap Securing cables and preventing abrasion
Insulation tape
Industrial strength hook and loop tape
Wrenches:
l
SAE
l
Metric open
l
Metric and imperial allen keys
l
1 1/8 inch box/open end
l
Socket
l
Torque drivers
For fitting to specification
Red Loctite (P/N33803)
Blue Loctite (P/N3207-1340)
Preventing screws and bolts from loosening
Anti seize compound
Contact cleaner
GCS900 Grade Control System for Excavators Installation Manual 25
