Bench testing and basic configuration 4
dimensions into the system.
Note Configure and label each sensor with their physical position on the
excavator arm.
For more information, see:
l A.3 Machine settings
l 9.13 Arm sensor connections
l A.5 Cab rotation sensor configuration
4.2.4 Check component connections
Use the Diagnostics dialog to check that all the system components are connected
to the control box. For more information see A.15 Diagnostics.
If a required device has a status of Not Found, see See "Validation and
Troubleshooting" on page 163.
GCS900 Grade Control System for Excavators Installation Manual 31
