2D system measurements 9
1
COR
2
Boom pin centerline
9.11 Machine dimensions
Use the Machine Dimensions wizards to enter your machine measurements into the
system.
To access the dialog, from Setup Menu – Installation, select Machine Dimensions:
The measurement types that appear depend on the type of system that you are
currently using (3D or Depth and Slope).The Body Vector Measurements option
does not appear for Depth and Slope systems.
