Installation Workflow 2
Procedure For more information see ...
Set the angle sensor orientation
9.14 AS300 / AS45x Sensor Orientation
Calibrate the angle sensors
9.15.2 Angle sensor calibration
Configure the lightbars (if installed)
A.6 External lightbar configuration
Define the bucket
9.12 Create bucket
Validate the tilt bucket
C.3 Validating the tilt bucket
Check the arm sensor calibrations, arm
positions and arm lengths
C.5 Checking the arm lengths
Validate the bucket guidance
C.4 Validating the bucket guidance
Validate the install
Chapter C, Validation and Troubleshooting
During the installation you may also want to save the system settings. See A.16
Saving the settings.
For more information, refer to the GCS900 Grade Control System Site Supervisor’s
Manual.
2.2 Machine-specific installation kits
Some machine-specific installation kits have supplementary instructions for
individual machines. When installing a machine kit, ensure that you refer to the
accompanying documentation along with the information contained in this manual.
For more information about available kits, contact your dealer.
