Installing theMain Harness Assembly 5
ATTENTION — Do not cut off any left over cabling, as this could affect system performance.
Bundle, tie wrap and store any extra cabling in a convenient place on the machine.
Once you have installed the cables, you must check the installation. For more
information, see C.2 Validating the cabling installation.
5.3 Excavator harnesses
This cable ... Provides connections to the ...
Bucket harness – unarmored bucket cable, armored tilt
bucket cable
(P/N 5841-xx)
l
AS450 bucket angle sensor
l
AS450 tilt bucket angle sensor
armored cable
l
AS455 bucket rotation sensor
l
stick harness
Bucket harness – armored bucket and tilt bucket cables
(P/N 66685-xx)
l
AS450 bucket angle sensor
armored cable
l
AS450 tilt bucket angle sensor
armored cable
l
AS455 bucket rotation sensor
l
stick harness
Bucket harness – armored bucket cable
(P/N 68450-xx)
l
AS450 bucket angle sensor
armored cable
l
stick harness
Stick harness (P/N 52142-xx)
l
stick harness
l
AS450 stick angle sensor or
LC450 laser catcher
l
boom harness
VAboom harness (P/N 52141-xx) – optional
l
stick harness
l
AS450 VA boom sensor
l
boom harness
Boom harness (P/N 52141-xx)
l
stick harness
l
AS450 boom angle sensor
l
front body harness
Front body harness (P/N 58479-xx)
l
boom harness
l
AS460 body angle sensor
l
rear body harness
GCS900 Grade Control System for Excavators Installation Manual 35
