3 Preparingfor anInstallation
This tool ... For...
Rust prevention touch-up paint Protecting welds and any machine parts stripped
of paint during the install
RTV silicone sealer Sealing cable entry holes
Steel tape or ruler
Straight edge
Framing square
Digital or spirit level
Digital or spirit level
Note – A digital level is essential for a UTS
system measure-up
A plumb line and string
Drill sets
Hole saws
A grinder
Clamps
A step ladder Reaching the higher parts of the machine
3.4 Operational considerations
When you install the equipment, pay attention to the following:
l Safety: Do not remove or obstruct:
Mirrors
Hand rails
Lights
Alarms
Horns
l Do not mount equipment where it obstructs the operator’s view, or could come
into contact with the operator during normal operation
l Ergonomics: Mount equipment so that:
the operator can see the control box screen in their normal field of vision,
and easily reach the control box from their normal, seated position
it does not block access for maintenance, or interfere with normal
operation of the machine.
26 GCS900 Grade Control System for Excavators Installation Manual
