Trimble GCS900 Installation Manual

A SetupMenus
5. Select Direct Connection.
A.10 Control box’s radio port
The Control Box’s Radio Port menu item is only available when you select a third
party radio in the Machine Settings wizard.
From Setup Menu – Installation, select Control Box’s Radio Port:
To ... Press ...
Enter values into the current field
][(
or
)
Swap between the fields
N
Cancel any changes
=
Save the changes
\
For a third-party radio
The settings in the Control Box’s Radio Port group must match the communication
port settings in the data radio.
150 GCS900 GradeControl System for Excavators Installation Manual

Trimble GCS900 Specifications

General

System Type	Grade Control System
Technology	GNSS, GPS, Laser
Connectivity	Wireless
GNSS Support	GPS, GLONASS, Galileo, BeiDou
Power Supply	12-24V DC
Operating Temperature	-20°C to 55°C
IP Rating	IP67
Accuracy	Sub-inch to centimeter level
Storage Temperature	-40°C to +70°C (-40°F to +158°F) (typical, component dependent)
