USTER HVI 900 - Page 260

USTER® HVI 900 Instruction Manual
Uster Technologies, Inc. Chapter 13
Version 4.0 (1.99) Fibrosampler - Page 13-10
Position Description Position Description
1 Fibrosampler Pivot
Assembly
13 Plastic Handle
2 Fibrosampler Comb
Holder
Assembly
14 M6 x 25mm FHSCS
3 Sample Chamber
Assembly
15 M5 Shoulder Screw
4 Fibrosampler Stand
Assembly
16 Bellville Washer
5 Fibrosampler
Counterweight
17 M6 x 25mm SHCS
6 Fibrosampler Spool 18 Loctite 262 Adhesive
7 M6 x 12mm Brass Tipped
Set Screw
19 Loctite 609 Retaining
Compound
8 Bearing Retainer 20 Loctite 242 Adhesive
9 Ball Bearing 21 Shaft Retainer
10 M6 Shoulder Screw 22 Warning Label
11 Bellville Washer 23 Column Label
12 M6 x 25mm Set Screw
• Remove the Fibrosampler carefully from the packing case.
• Attach the base to the column with the M10 socket head capscrew
(SHCS) and washer provided. Orient the sockets in the column
toward one side of the base. The screw should be tight enough to
prevent rotation of the post during operation.
• Attach the drum assembly to the column with the M6 socket head
cap screw provided.
• Inspect the card cloth on the left of the sample drum for shipping
damage. Notify the carrier and Uster Technologies if there is any
damage.
• Slowly, rotate the operating handle completely around the drum to
ensure that it has free movement.
