USTER® HVI 900 Instruction Manual
Uster Technologies, Inc. Chapter 14
Version 4.0 (1.99) Appendix - Page 14-41
14 HVI 900A System Installation
Guide/Report
1. General Connections
[ ] Check to see that all the cables are properly seated. Refer to the
Service Manual for the location of the cables to the multifunction
board.
_____ Connect the AC to the instrument. Measure and record the AC
voltage.
_____ Connect the air supply. Record the main inlet pressure in psi
from the instrument gauge.
2. Color Module Installation
[ ] Remove the lamps and burnish the contacts. Re-install the lamps.
[ ] Adjust all the pots on the color head for proper voltages. Refer
to the Service Manual for the location of these.
_____ Record the air pressure of the color hand (standard is 40 psi).
[ ] Check the values of the color tiles in status.
[ ] Calibrate with the color tiles.
