Pos. Ind. Part No. Quantity Description Remark
362 2 94322 1 Piece Support Y = 460 mm
363 2 94324 1 Piece Lifting tool X = 336 mm, Mass approx. 56.9 kg,
(WLL 8200 kg)
364 2 94321 1 Piece Link X = 268 mm
365 2 94325 1 Piece Chain X = 424 mm, Mass approx. 4 kg,
(WLL 1500 kg)
nil 1 - Tool con. rod/crosshead assembly
(With I-ELBA)
-
367 2 94322 1 Piece Support Y = 460 mm
368 2 94324 1 Piece Lifting tool X = 336 mm, Mass approx. 56.9 kg,
(WLL 8200 kg)
369 2 94321 1 Piece Link X = 268 mm
370 2 94325 1 Piece Chain X = 424 mm, Mass approx. 4 kg,
(WLL 1500 kg)
371 2 94322A 1 Piece Support Y = 800 mm
nil 1 - Tool crosshead bearing lubr. -
373 2 94336 1 Piece Re-lubrication X = Ø 140 mm
nil 1 - Tool connecting rod assembly -
375 2 94337 2 Pieces Lifting tool Y = 478 mm,WLL:− vertical 4000 kg −
horizontal 2600 kg
376 2 94334A 1 Piece Tool connecting rod assembly X = 116 mm, (WLL 4500 kg)
377 2 94334 1 Piece Tool connecting rod assembly X = 1448 mm, Mass approx. 134 kg
nil 1 - Tool connec. rod bear. inspect. -
379 2 94335 1 Piece Stop plate X = 226 mm
380 2 TN 94117 1 Piece Chain Y = 314 mm, WLL 1000 kg
nil 1 - Tool connec. rod bearing assy -
382 2 94333 1 Piece Lifting tool X =800 mm
383 4 94333A 2 Pieces Bolt Y = 291 mm
nil 1 - Tool bear. shell crank pin assy -
385 2 94326 1 Piece Fitting and dismantling device X = 340 mm, Mass approx. 21 kg,
WLL 60 kg
386 2 94327 1 Piece Chain -
nil 1 - Tool piston assembly (ISO) -
388 2 94350 1 Piece Piston support/dismant.gland box X = 1030 mm, Y = 1351 mm, Z =
1342 mm, Mass approx. 420 kg
389 2 94341 1 Piece Lifting tool Y = 345 mm
390 2 94342 1 Piece Dismantling and assembling tool X = 818 mm
391 2 94209 1 Piece Wire rope X = 1000 mm, WLL 750 kg
392 2 94208 1 Piece Dismantling tool X = 638.5 mm
393 2 94344 1 Piece Dismantling and assembling tool -
394 3 94344A 1 Piece Distance bush X = 405 mm
395 3 94344B 2 Pieces Chain -
nil 1 - Tool piston assembly (JIS) -
397 2 TN 94162 1 Piece Piston support/dismant.gland box X = 1040 mm, Y = 1346 mm, Z =
1352 mm, Mass approx. 377 kg
398 2 TN 94163 1 Piece Lifting tool Y = 345 mm
399 2 94342 1 Piece Dismantling and assembling tool X = 818 mm
400 2 94209 1 Piece Wire rope X = 1000 mm, WLL 750 kg
401 2 94208 1 Piece Dismantling tool X = 638.5 mm
402 2 94344 1 Piece Dismantling and assembling tool -
X62DF
AA00-0000-00AAA-941A-C
Maintenance Manual Standard tools
Winterthur Gas & Diesel Ltd.
- 862 - Issue 002 2020-10
