February, 2008
6-37
WorkCentre 5225, 5230
IIT NVM List
General Procedures
Launch Version
715-606 MAE Line to Fix Variation 240 0~65535 End position for AE in the slow scan direction. Width in the slow scan direction for detecting back-
ground density with RAE. MAESSE (*Also applies to detection area for PreIPS noise deletion.)
715-607 NAE Line to Fix Variation 240 0~65535 End position for AE in the slow scan direction. Width in the slow scan direction for detecting back-
ground density with RAE. NAESSE
715-608 Variation Control for BW Copy 1 0~1 LIM Control mode
715-609 CL_Copy Variation Control 1 0~1 LIM Control mode
715-610 Variation Control for FAX, BinScan 1 0~1 LIM Control mode
715-611 Variation Control for ContoneScan 1 0~1 LIM Control mode
715-612 HAE Threshold for Background Color Suppres-
sion
127 0~255 Threshold value for histogram of HAE. Set in 100/255 increments. HAETH
715-613 NAE1 Threshold for Background Color Suppres-
sion
33 0~255 Threshold value for the number of color blocks of NAE. Set in 100/255% increments. NAEBLKTHC
715-614 NAE2 Threshold for Background Color Suppres-
sion
204 0~255 Threshold value for the number of designated color blocks of NAE. Set in 100/255% increments.
NAEBLKTHY
715-615 NAE3 Threshold for Background Color Suppres-
sion
8 0~65535 Threshold value for the number of color lines of NAE. Designates the number of lines. NAETHC
715-616 NAE4 Threshold for Background Color Suppres-
sion
4 0~65535 Threshold value for the number of color lines of NAE. The number of lines is set. NAETHY
715-617 AE Control of FS Length 0 0~1 0: Always use the document size detection result, 1: Detects the document size which the user
enters for calculating the AES parameter
715-618 Minimum FS Length for AE 500 0~65535 Fast Scan Detection Min range (0.1mm increments) for AES parameter calculation.
715-619 RAE Upper Limit 1 of SS Enlargement Correction
Value for Adjusting AE Parameter
4000 0~4000 Slow Scan Detection Max range (0.1% increments) for RAE.
715-620 MAE Upper Limit 1 of SS Enlargement Correction
Value for Adjusting AE Parameter
4000 0~4000 Slow Scan Detection Max range (0.1% increments) for MAE.
715-621 HAE Upper Limit 1 of SS Enlargement Correction
Value for Adjusting AE Parameter
4000 0~4000 Slow Scan Detection Max range (0.1% increments) for HAE.
715-622 NAE Upper Limit 1 of SS Enlargement Correction
Value for Adjusting AE Parameter
4000 0~4000 Slow Scan Detection Max range (0.1% increments) for NAE.
715-629 TX_BW_Fax Offset Level of AE 0 0~8191 0 to 3 bits: Platen 0: Strength level 0 (standard), 1: Strength level 1, 2: Strength level 2, 3: Strength
level 3, 4: Strength level 4, 5or more: Strength level 0 (standard)
4 to 7 bits: CVT or machines with DADF 0: Strength level 0 (standard), 1: Strength level 1, 2:
Strength level 2, 3: Strength level 3, 4: Strength level 4, 5or more: Strength level 0 (standard)
8 to 11 bits: CVT or machines with DADF (duplex copy) 0: Strength level 0 (standard), 1: Strength
level 1, 2: Strength level 2, 3: Strength level 3, 4: Strength level 4, 5or more: Strength level 0 (stan
-
dard)
12 bits: On/Off of this register 1: On
715-630 TP_BW_Copy_Fax Suppression Level of AE
(Print, Photograph, Copy)
0 0~4095 0: Strength Level 0 (standard), 1: Strength Level 1, 2: Strength Level 2, 3: Strength Level 3, 4:
Strength Level 4, 5~15 and above: Strength Level 0 (standard) 0bit~3bit, Platen 4bit~7bit, CVT or
DADF 8bit~11bit, CVT or DADF 2 Sided Copy (* Used as the PreIPS EAER_DAT suppression level
as well)
715-631 TP_BW_Copy_Fax Offset Level of AE (Print,
Photograph, Copy)
273 0~4095 0: Strength Level 0 (standard), 1: Strength Level 1, 2: Strength Level 2, 3: Strength Level 3, 4:
Strength Level 4, 5~15 and above: Strength Level 0 (standard) 0bit~3bit, Platen 4bit~7bit, CVT or
DADF 8bit~11bit, CVT or DADF 2 Sided Copy
Table 2 IISS
Chain-Link Content Default Range Meaning
