Page #532 background imageLoading...
Page #532 background image
February, 2008
2-509
WorkCentre 5225, 5230
061-315, 061-321
Status Indicator Raps
Launch Version
061-315 Start Of Scan RAP
BSD-ON:6.4
The light intensity of the LD2 does not reach the specified value.
Procedure
Check the connections of P/J406 on the MCU PWB and P/J140 on the ROS Unit. Connec-
tions are connected correctly.
YN
Connect P/J406 and P/J140.
Check the wires between J406 and J140 for an open circuit or a short circuit (BSD 6.4 Flag 1/
Flag 2).
The wires are conducting without an open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Replace the ROS Unit (PL 3.1)
If the problem persists, replace the MCU PWB (PL 9.1).
061-321 ROS Motor RAP
BSD-ON:6.4/6.5
The ROS Motor rotation speed does not reach the specified value within the specified time
after the ROS Motor started rotating.
The light intensity of the LD1 does not reach the specified value.
Procedure
Check the connections of P/J406 on the MCU PWB and P/J140 on the ROS Unit. Connec-
tions are connected correctly.
YN
Connect P/J406 and P/J140.
Check the connections of P/J160 and P/J170. P/J160 and P/J170 are connected cor-
rectly.
YN
Connect P/J160 and P/J170.
Check the wire between J406 and J140 for an open circuit or a short circuit (BSD 6.4 Flag 1/
Flag 2).
The wire between J406 and J140 is conducting without an open circuit or a short
circuit.
YN
Repair the open circuit or short circuit.
Check the wire between J406 and J130 for an open circuit or a short circuit (BSD 6.5 Flag 1).
The wire between J406 and J130 is conducting without an open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Execute Component Control[061-200 ROS MOTOR ON]. The ROS Motor can be heard.
YN
Measure the voltage between the MCU PWB P406-10 (+) and GND (-) (BSD 6.5 Flag 2).
The voltage is +24VDC.
YN
Measure the voltage between the MCU PWB P400-1 (+) and GND (-) (BSD 1.2 Flag
1).
The voltage is +24VDC.
YN
Measure the voltage between the Power Unit P526-4 (+) and GND (-) (BSD 1.2
Flag 1).
The voltage is +24VDC.
YN
Replace the Power Unit (PL 9.1).
Repair the open circuit between J526 and J400.
Replace the MCU PWB (PL 9.1).
Replace the ROS Unit (PL 3.1) If the problem persists, replace the MCU PWB (PL 9.1).
Install the Xero/Developer Cartridge securely.
Measure the voltage between the MCU PWB P406-2 (+) and GND (-) (BSD 6.4 Flag 3). The
voltage is +5VDC.
