Xerox WorkCentre 5225

February, 2008
2-518
WorkCentre 5225, 5230
062-393, 062-500
Launch Version
Status Indicator Raps
062-393 IIT/IPS PWB RAM RAP
BSD-ON: 6.2
An internal processing error occurred in the IIT/IPS PWB.
Procedure
Check the connection of each IIT/IPS PWB (PL 13.3) connector. The connectors are
securely connected.
YN
Connect the connectors.
Switch on the power.
If the problem persists replace the IIT/IPS PWB (PL 11.3).
If the problem persists, replace the Lens Kit Assembly (PL 11.3).
062-500 IISS ROM RAP
BSD-ON: 6.2
IISS ROM Failure.
Procedure
Check the connections on the IIT/IPS PWS (PL 11.3).
Check that the prom on the IIT/IPS PWB is seated properly.
If the above checks are OK, replace the IIT/IPS PWB (PL 11.3).
Perform Max Setup if the IIT/IPS PWB was replaced.
Perform DADF Registration Setup (ADJ 15.1.4).
