February, 2008
2-528
WorkCentre 5225, 5230
072-211 , 071-940
Launch Version
Status Indicator Raps
072-211 Tray 2 Broken RAP
BSD-ON:7.2
The Tray 2 Paper Size Switch failed.
Initial Actions
• Reload the tray correctly.
• Check the operation of the tray actuator.
• Power OFF/ON
Procedure
Remove Trays 1 and 2. Replace Tray 1 with Tray 2. [072-211] occurs.
YN
Replace the faulty part of the Tray 2 Actuator.
Check the installation of the Tray 2 Paper Size Switch. The Tray 2 Paper Size Switch is
installed correctly.
YN
Install the Tray 2 Paper Size Switch correctly.
Go to the OF 2 (SIZE SWITCH ASSY RAP).
071-940 Tray 2 Lift Up RAP
BSD-ON:7.1
The Tray 2
Level Sensor does not turn on within the designated time.
Initial Actions
• Remove and reinsert Tray 2
• Realign paper in the tray
• Object other than paper is in the tray
Procedure
1. Tray Level Sensor
2. Drive system from motor to bottom plate
To Next Page
