Xerox WorkCentre 5225 Service Manual

February, 2008
6-60
WorkCentre 5225, 5230
Launch Version
General Procedures
Chain 720-xxx Meter Counter
Chain 731-xxx Chain 732-xxx Stored Data
711-477 DADF Stamp Solenoid Life Count (lower digits) 34464 0~65535 -
711-478 DADF Stamp Solenoid Ink Life Count (upper dig-
its)
0 0~65535 - 3K * Life value may be changed in Counter Write Command. It cannot be written in
Chain Link setting.
711-479 DADF Stamp Solenoid Ink Life Count (lower digits) 3000 0~65535 -
Table 2 CVT DADF NVM LIST
Chain-Link Content Default Range 1 Count Meaning
Table 3 Meter Counter
Chain-
Link
Content Default Range Meaning
720-002 Billing 1 1~7 Billing1: 1, Billing2: 2, Billing3: 3, Billing4: 4, Billing5: 5, Billing6: 6, Billing7: 7
720-003 Master Print-Full Color - 0~19999999 [0~19,999,999]
720-004 Master Print-Color1 - 0~19999999 [0~19,999,999]
720-005 Master Print-Color2 - 0~19999999 [0~19,999,999]
720-006 Master Print-B - 0~19999999 [0~19,999,999]
720-007 Master Copy-Full Color Counter - 0~19999999 [0~19,999,999]
720-008 Master Copy-Color2 Counter - 0~19999999 [0~19,999,999]
720-009 Master Copy-B Counter - 0~19999999 [0~19,999,999]
720-010 Master FAX-Full Color Counter - 0~19999999 [0~19,999,999]
720-011 Master FAX-B Counter - 0~19999999 [0~19,999,999]
720-046 Master Large Size B Counter - 0~19999999 [0~19,999,999]
720-047 Master Large Size Color Counter - 0~19999999 [0~19,999,999]
720-052 Billing Type STANDARD: 0 0~2 [STANDARD: 0, CUSTOM1: 1, CUSTOM2: 2]
720-053 Master Modal Color Counter - 0~19999999 [0~19,999,999]
720-054 Master Modal B Counter - 0~19999999 [0~19,999,999]
720-057 Billing Modal Break Point 10 10~100 [10~100]
730-010 Pay for Print - Correct Account 0 0~1 0: Print, 1: Forcibly store
730-011 Device Total Impressions 0 0~FFFFFFFF 0 to FFFFFFFF
730-012 Device Impressions Limit 9,999,999 0~9,999,999 0: Print prohibited, 1 to 9,999,998: Upper limit, 9,999,999: No limit
730-013 Device Impressions Limit Warning Rate 80 0~100 Percentage (%) with respect to the maximum number of print impressions used for indicat-
ing warning
Table 4 Stored Data
Chain-
Link
Content Default Range Meaning
731-
001~999
Speed Dial setting for Modem Speed (Link
1-500)
0: Follow system data for
modem speed
0~14 [Follow system data for modem speed=0, 2400bps=1, 4800bps=2, 7200bps=3, 9600bps=4,
12000bps=5, 144000bps=6, 16800bps=7, 19200bps=8, 21600bps=9, 24000bps=10,
26400bps=11, 28800bps=12, 31200bps=13, 33600bps=14]
