February, 2008
6-59
WorkCentre 5225, 5230
General Procedures
Launch Version
711-213 DADF Stamp Solenoid On Time Adjustment 5 3~20 2msec Initial value 10ms +30ms/-4ms, 2ms increments
711-214 DADF Stamp Position Adjustment 15 0~30 0.5mm Initial value 0mm +7.5mm/-7.5mm, approx. 0.5mm increments Initial value is 10mm
from Tail Edge.
711-215 Slow Down Start Time Adjustment Value during
Nudger Lift Down (T11 ms)
10 0~20 4msec Initial value 0ms +/-40ms, 4ms increments
711-216 Slow Down Start Time Adjustment Value during
Nudger Lift Up (T12 ms)
10 10~20 4msec Initial value0ms +40ms/-0ms, 4ms increments
711-217 Feed Out Sensor Static Jam Detection Sampling
No. Setting
20 1~40 1 time Initial value 20 times +20 times/-19 times, 1 time increments
711-218 Feed Out Sensor Act. Correction Coefficient - A9 59 0~255 0.01 Initial value 0.59 0.00~2.55, 0.01 increments
711-219 Feed Out Sensor Act. Correction Coefficient - B9 104 0~255 1 Initial value 104 0~255, 1 increments
711-270 ADF-IIT Combine Adjustment Value Data 1 0 0~255 - Adjustment Value Data 1 sent to IIT during ADF-IIT Combine.
711-271 ADF-IIT Combine Adjustment Value Data 2 0 0~255 - Adjustment Value Data 2 sent to IIT during ADF-IIT Combine.
711-272 ADF-IIT Combine Adjustment Value Data 3 0 0~255 - Adjustment Value Data 3 sent to IIT during ADF-IIT Combine.
711-273 ADF-IIT Combine Adjustment Value Data 4 0 0~255 - Adjustment Value Data 4 sent to IIT during ADF-IIT Combine.
711-274 ADF-IIT Combine Adjustment Value Data 5 0 0~255 - Adjustment Value Data 5 sent to IIT during ADF-IIT Combine.
711-275 ADF-IIT Combine Adjustment Value Data 6 0 0~255 - Adjustment Value Data 6 sent to IIT during ADF-IIT Combine.
711-276 ADF-IIT Combine Adjustment Value Data 7 0 0~255 - Adjustment Value Data 7 sent to IIT during ADF-IIT Combine.
711-277 ADF-IIT Combine Adjustment Value Data 8 0 0~255 - Adjustment Value Data 8 sent to IIT during ADF-IIT Combine.
711-278 ADF-IIT Combine Adjustment Value Data 9 0 0~255 - Adjustment Value Data 9 sent to IIT during ADF-IIT Combine.
711-279 ADF-IIT Combine Adjustment Value Data 10 0 0~255 - Adjustment Value Data 10 sent to IIT during ADF-IIT Combine.
711-280 ADF-IIT Combine Adjustment Value Data 11 0 0~255 - Adjustment Value Data 11 sent to IIT during ADF-IIT Combine.
711-281 ADF-IIT Combine Adjustment Value Data 12 0 0~255 - Adjustment Value Data 12 sent to IIT during ADF-IIT Combine.
711-282 ADF-IIT Combine Adjustment Value Data 13 0 0~255 - Adjustment Value Data 13 sent to IIT during ADF-IIT Combine.
711-283 ADF-IIT Combine Adjustment Value Data 14 0 0~255 - Adjustment Value Data 14 sent to IIT during ADF-IIT Combine.
711-284 ADF-IIT Combine Adjustment Value Data 15 0 0~255 - Adjustment Value Data 15 sent to IIT during ADF-IIT Combine.
711-297 Communication Fail Bypass 0 0~1 - 0: Disable Communication Fail Bypass 1: Enable Communication Fail Bypass
711-468 DADF Open/Close Life Count (upper digits) 3 0~65535 - 260K * Life value may be changed in Counter Write Command. It cannot be written in
Chain Link setting.
711-469 DADF Open/Close Life Count (lower digits) 63392 0~65535 -
711-470 DADF Document Feed Life Count (upper digits) 3 0~65535 - 200K * Life value may be changed in Counter Write Command. It cannot be written in
Chain Link setting.
711-471 DADF Document Feed Life Count (lower digits) 3392 0~65535 -
711-472 DADF Simplex and Duplex Document Feed Life
Count (upper digits)
13 0~65535 - 912K * Life value may be changed in Counter Write Command. It cannot be written in
Chain Link setting.
711-473 DADF Simplex and Duplex Document Feed Life
Count (lower digits)
60032 0~65535 -
711-474 Invert Solenoid Life Count (upper digits) 7 0~65535 - 500K * Life value may be changed in Counter Write Command. It cannot be written in
Chain Link setting.
711-475 Invert Solenoid Life Count (lower digits) 41248 0~65535 -
711-476 DADF Stamp Solenoid Life Count (upper digits) 1 0~65535 - 100K * Life value may be changed in Counter Write Command. It cannot be written in
Chain Link setting.
Table 2 CVT DADF NVM LIST
Chain-Link Content Default Range 1 Count Meaning
