Xerox WorkCentre 5225

February, 2008
2-690
WorkCentre 5225, 5230
124-393, 124-701
Launch Version
Status Indicator Raps
124-393 CRU OEM System 2 (2)
OEM (Original Equipment Manufacturer) CRUM control failed in system 2.
Procedure
Check the electrical connections on the ESS PWB and MCU PWB. The connectors are securely
connected.
YN
Connect the connectors.
Turn on the power again. The problem persists.
YN
Return to Service Call Procedures.
Perform GP 4, repair the problem by master SYS2.
If the problem persists, replace the ESS PWB (PL 9.2).
124-701 Side Tray to Center Tray RAP
The output destination was changed by the customer from the Side Tray to the Center Tray.
Procedure
No action necessary.
