February, 2008
2-571
WorkCentre 5225, 5230
091-916
Status Indicator Raps
Launch Version
091-916 Xero CRUM Match RAP
BSD-ON:9.1
The Control Logic detected mismatched data on the Xero CRUM.
Initial Actions
Check NVM location 740-047, for Geographic area:
• NA/EU = 3
• DMO-E/W = 12
• All the World = 512
Check NVM location 740-049, for Contact Type:
• Metered = 3
• Sold = 2
• Neutral = 31
Procedure
Pull out and reinstall the Xerographics Drum Module. The problem persists.
YN
Return to Service Call Procedures.
An incorrect Xerographics Drum Module was installed. Verify the position of the Xerographics
Drum Module. Install the correct Xerographics Drum Module.
To Next Page
