Xerox WorkCentre 5225 Service Manual

February, 2008
6-53
WorkCentre 5225, 5230
General Procedures
Launch Version
700-624 Netauth KDC Info - Server Port Number for
Backup 4
88 1~65535 1 to 65535
700-625 Netauth KDC Info - Server Port Number for
Backup 5
88 1~65535 1 to 65535
700-626 Netauth Authagent Info - Timeout 60 1~300 1 to 300 (seconds)
700-627 Netauth LDAP Info - Auth Sequence 0 0~1 0: Direct login, 1: Search and login
700-628 Netauth LDAP Info - Login User Login
Attribute
“samAccountName” Character string (32 ASCII characters)
700-629 Netauth LDAP Info - Login User Search
Attribute
“mail” Character string (32 ASCII characters)
700-630 Netauth LDAP Info - User String Added Null Character string (64 ASCII characters)
700-631 Netauth LDAP Info - Add User String 0 0~1 0: Disable, 1: Enable
700-632 Netauth SMB Info - Domain Name 1 Null Character string (15 ASCII characters)
700-633 Netauth SMB Info - Domain Name 2 Null Character string (15 ASCII characters)
700-634 Netauth SMB Info - Domain Name 3 Null Character string (15 ASCII characters)
700-635 Netauth SMB Info - Domain Name 4 Null Character string (15 ASCII characters)
700-636 Netauth SMB Info - Domain Name 5 Null Character string (15 ASCII characters)
700-642 Netauth SMB Info - Server/SMB Name 1 Null One of the following can be entered:FQDN, IPv6 address (literal format), IPv4 (literal for-
mat). The character string shall be null-terminated.
Restrictions when specifying NetBIOS host name: the following 15 characters cannot be
used: “* +, /:; < = >? [\] |
Entry is prohibited if space is designated either at the end or beginning of the character
string or if the character string consists of period only. The maximum number of bytes shall
be 16 (including null characters).
Restrictions when specifying FQDN: The following characters can be used: 1-byte alphanu-
meric characters, 1-byte hyphens (-), and periods (.). Entry is prohibited if 1-byte hyphen is
specified either at the beginning or the end of the character string.
700-643 Netauth SMB Info - Server/SMB Name 2 Null One of the following can be entered:FQDN, IPv6 address (literal format), IPv4 (literal for-
mat). The character string shall be null-terminated.
Restrictions when specifying NetBIOS host name: the following 15 characters cannot be
used: “* +, /:; < = >? [\] |
Entry is prohibited if space is designated either at the end or beginning of the character
string or if the character string consists of period only. The maximum number of bytes shall
be 16 (including null characters).
Restrictions when specifying FQDN: The following characters can be used: 1-byte alphanu-
meric characters, 1-byte hyphens (-), and periods (.). Entry is prohibited if 1-byte hyphen is
specified either at the beginning or the end of the character string.
Table 1 Common
Chain-
Link Content Default Range Meaning
