Xerox WorkCentre 5225 Service Manual

February, 2008
6-116
WorkCentre 5225, 5230
Initialize HFSI Counters
Launch Version
General Procedures
954-803 Tray4 5th&6thDigits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-803 Tray4 3rd&4thDigits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-803 Tray4 First 2Digits of Feed Capacity (8 Digits) 0 0~3 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-804 HCF Last 2Digits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-804 HCF 5th&6thDigits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-804 HCF 3rd&4thDigits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-804 HCF First 2Digits of Feed Capacity (8 Digits) 0 0~3 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-805 MPT Last 2Digits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-805 MPT 5th&6thDigits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-805 MPT 3rd&4thDigits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-805 MPT First 2Digits of Feed Capacity (8 Digits) 0 0~3 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-808 Last 2Digits of the number of Sheets Reaching BIAS transfer
Roll(8 Digits)
0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-808 5th&6thDigits of the number of Sheets Reaching BIAS transfer
Roll(8 Digits)
0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-808 3rd&4thDigits of the number of Sheets Reaching BIAS transfer
Roll(8 Digits)
0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-808 First 2Digits of the number of Sheets Reaching BIAS transfer
Roll(8 Digits)
0 0~3 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
Table 1 IOT HFSI
Chain-Link Name
Initial
Value Value 1Count Remarks
